fischer Roof Hooks RH 52-67 HB AL Aluminium Pack of 10

Features: The roof hook has four adjustment elements: the horizontal adjustment on the base plate allows you to adjust to the roof tile, the lower one allows adjustment to different tile thicknesses, the middle vertical allows you to adjust the distance profile to the tile top, the upper allows the rail to be horizontally aligned. Suitable for roof tiles with a total thickness of 40 to 52 mm (57174 5) or 52 up to 67 mm (571747). The quick coupling hook/rail does not require additional screws. The wide base plate provides variable attachment to the counter plate. Versatile holes increase the selection in the mounting arrangement. The large load capacity allows the use of fewer roof hooks. The roof hook offers several adjustment elements: the lower allows adjustment to the tile thickness, the vertical adjustment element at the top allows the adjustment of the stands between profile and Z. stands Seal top. The top adjustment option allows the rail to be aligned parallel to the eaves / ridge. Attachment with A2-PowerFast screws, either three screws Ø6 or two screws Ø8. The high load capacity allows the use of fewer roof hooks. The roof hook has a controlled deformation and is designed to not bend or damage the tiles. The roof hook is pre-assembled and can be mounted without additional accessories. The roof hook is stable, lightweight and made of aluminium, To ensure the long service life of the system. By turning the joint, the roof hook is compatible with both SolarLight and SolarFish rails. Determine the axle distance of the roof hooks according to the snow and wind loads on site and set the position depending on the supporting structure and local conditions. Please note: decoration not included.
