LRS-200-12 12V 17A 200W Industrial Power Supply with 85-264VAC Input, Overload Protection for Automation Systems & Electronic Equipment

The LRS-200-12 industrial switching power supply delivers reliable 12V/17A DC output (204W maximum) for demanding applications. Engineered with a wide 85-264VAC input range (switch-selectable 115V/230V mode) and 240-370VDC compatibility, it ensures stable operation under fluctuating grid conditions. Key technical specifications include 87.5% conversion efficiency, ±1% voltage regulation, and <100mVp-p ripple noise. The unit features comprehensive protection: automatic recovery from 110-140% overload conditions, 135-150% over-voltage cutoff, and thermal shutdown above 70°C. Its industrial-grade construction includes a 30mm low-profile (1U) steel case with IP20 protection, capable of withstanding 5G vibration across three axes and operating in -30°C to +70°C environments. Compliant with UL62368-1, EN61558, and EN55035 standards, it meets global safety requirements while achieving <0.75W standby consumption for energy compliance. The screw terminal block supports 12-10AWG wiring, and the built-in LED power indicator simplifies status monitoring. With 100% full-load burn-in testing and 3-year warranty, this 215×115×30mm (8.46×4.53×1.18in) power supply is ideal for factory automation, test benches, telecommunications gear, and 12V motor control systems requiring compact, high-reliability power conversion.

• High-Efficiency Industrial Power Solution: Delivers 12V DC output with 87.5% efficiency and 200W continuous power (204W peak), optimized for industrial automation systems, control panels, and electronic devices requiring stable 12V/17A power supply.
• Wide Voltage Input & Robust Protection: Features switch-selectable 85-264VAC input range (90-132VAC/180-264VAC) and 240-370VDC compatibility. Built-in safeguards include overload (110-140% capacity), short-circuit, over-voltage, and over-temperature protection with auto-recovery.
• Industrial-Grade Durability: Operates at -30°C to +70°C with metal mesh housing for superior heat dissipation. Withstands 5G vibration (10-500Hz) and functions at up to 5,000m altitude, certified to UL62368-1, EN55035, and EN61558 standards.
• Energy-Saving & Maintenance-Free Design: Achieves <0.75W no-load power consumption and 0.75mA leakage current. Fanless operation with natural cooling ensures silent performance and extended lifespan (2,346.6K hours MTBF per Telcordia SR-332).
• Universal Installation Compatibility: Compact 215×115×30mm (1U height) chassis with screw terminal connections. Supports 100% full-load burn-in testing, ideal for CNC machines, PLC systems, lab equipment, and IoT devices requiring 12V DC power.
